|screen size||11.26 1920*440|
|Master chip||Allwinner V533|
|front lens||GC2093 1/2.9 60 FPS 2.8m|
|rear lens||AHD1080P1920*1080 /30FPS|
|Video resolution||2.5K 2560*1440/30FPS|
|touch operation||Support full screen touch|
|time lapse video||Support, ACC step-down line is required|
|GPS electronic dog||optional|
|switch logo||Support customization|
|WIFI function||Not support|
|powered by||5V 2A car charger or optional ACC step-down line|
|storage card||Maximum support 128GB|
|Operating temperature||-20 -70℃|
|Supported languages||Chinese. Traditional Chinese. English. Japanese. Russian.|
|Korean. French. Polish. German, Italian.|
|Thai, Vietnamese, Portuguese, etc. Support customization|
|Packing information||G.W.:1.0 kg|
|Color box size: 247MM*112MM*71MM|
|Carton size: 375MM*365MM*482MM|
|Qty: 20 PCS|
It use Original Allwinner Chip and Sony image sensor.Professional image processor and Sony sensor,picture quality is more detailed.
Compare to 1080P,2k resolution can greatly enhances nightvision and obtain sharp,color-accurate images,visible videoany situation-day or night.
1080P resolution clear viewing rear view images,and are-versing line Better than the original car reversing images,reversing more secure.
12-inch Full View Touch Screen provides crystal image without any delay.Very clear and smooth images display as like a stream flowing on the excellent WDR and Auto Adjusting Brightness Streaming Mirror.
It is equipped with this streaming media technology,makes the driving rear view angle more widely,it is triple wide view angle then the traditional mirror.Dvr use HD to provide you with flawless images in rain,fog,snow,or even at low-light level.
1:1 split screen design to switch front and rearview recording,big screen and clearly and ersily to check rear view.You can switch views by swiping your finger left or right.It contains 3 views:front view,rear view, front & rear view.
2.5D curved glass design,scratch-resistant,anti-glare,anti-fingerprint.
170 Degree Angle 1440P front camer with 140 Degree Angle 1080P Night vision Rear view Camera (Optional),allows for simultaneously recording videos from two different angles.Two split view make you have clear view from front and back-up camera.
Smart rear view angle switch between driving and parking.You could see all further vehicles and objects clearly behind.you while real-time driving and it will switch the rear view camera automatically to give a closer backup image when parking.
Taking a 16G memory card as an example, only about one hour of video can be recorded in the 30-frame per second mode. After the time-lapse recording function is enabled, recording time under 1 frame per second mode will reach 30 hours (more than 24 hours), which will increase the maximum recording time and data storage by 30 times, ensuring the integrity of the recorded content, greatly saving memory Card space and protect your vehicle for more than 24 hours.(Note: Need to buy a buck line)
If you are worried about your car being damaged by someone else after parking, you can use our buck line to connect the DVR to ensure that the recorder works 24 hours.If someone else hurts your car and the shock triggers the G-sensor, the DVR will immediately turn on and record the situation.
Use the buck line to not occupy the cigarette lighter interface.First, connect the negative pole(black line) of the buck line to the ground of the car fuse box;Secondly, if you want to continue monitoring after parking (the DVR works 24 hours), connect the positive pole(red line) of the buck line to the BAT interface of the car fuse box;If you want to stop monitoring after parking (the DVR does not work after parking), connect the positive pole of the buck line to the fuse box ACC interface.
SKU(Color Name) Packing List
With 6M RCC
-1 x DVR
-1 x Power charger
-1 x User Manual
-2 x Bandage
-1 x 1080P Rearview Camera With 6 Meters Cable
About Rear Camera Installation
Please connect the rear camera’s Red cable wire with your car reverse lamp power ‘s Positive pole(+).
and then plug the car charger into the cigar lighter to power supply the car dvr.
When you get your car in Reverse Gear, the car dvr will automatically switch to the rear camera with parking line.Then the auto reversing function will work.
